ZRT040GC1TA
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 ZRT040 Tape & Reel (TR) 2012 voltage reference device 150muA 4.01V 50muVp-p 50ppm/C
PDF
/
Buying Options
Total Price: USD $12.38
Unit Price: USD $12.38325
≥1 USD $12.38325
≥10 USD $10.1612
≥100 USD $9.8439
≥500 USD $9.52565
≥1000 USD $9.20835
Inventory: 1136
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.7mm
Length 6.7mm
Height 1.65mm
Technical
Noise - 0.1Hz to 10Hz 50μVp-p
Current - Cathode 150μA
Temp Coef of Voltage-Max 50 ppm/°C
Min Output Voltage 4.01V
Nominal Input Voltage 4.01V
Reference Type Shunt
Reference Voltage 4.01V
Max Output Voltage 4.01V
Max Supply Current 75mA
Operating Supply Current 75mA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Max Output Current 75mA
Output Type Fixed
Output Voltage 4.01V
Number of Outputs 1
JESD-30 Code R-PDSO-G4
Pin Count 4
Base Part Number ZRT040
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 50ppm/°C
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Tolerance ±1%
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 188.014037mg
Number of Pins 3
Package / Case TO-261-4, TO-261AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 19 Weeks
