ZRC500A01
RoHS
/
Package E-Line-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 ZRC500 Bulk MATTE TIN voltage reference device 25muA 5V 105muVrms 90ppm/C
PDF
/
Inventory: 7231
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 2.285mm
Length 4.57mm
Technical
Noise - 10Hz to 10kHz 105μVrms
Current - Cathode 25μA
Temp Coef of Voltage-Max 90 ppm/°C
Min Output Voltage 5V
Nominal Input Voltage 5V
Reference Type Shunt
Current - Output 5mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Number of Channels 1
Output Type Fixed
Output Voltage 5V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSIP-T3
Base Part Number ZRC500
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish MATTE TIN
Temperature Coefficient 90ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Tolerance ±1%
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Package / Case E-Line-3
Mounting Type Through Hole
Mount Through Hole
