ZR40401R25STOB
RoHS
/
Package E-Line-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Through Hole Lead Free RoHS Compliant SINGLE voltage reference device 4.01mm ±1% -40C~85C TA 45muVrms
PDF
/
Inventory: 2226
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 2.41mm
Length 4.77mm
Height 4.01mm
Technical
Noise - 10Hz to 10kHz 45μVrms
Current - Cathode 60μA
Min Output Voltage 2.5V
Nominal Input Voltage 2.45V
Reference Type Shunt
Current - Output 15mA
Nominal Supply Current 120mA
Operating Supply Current 120mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Number of Channels 1
Output Type Fixed
Output Voltage 2.5V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSIP-T3
Base Part Number ZR404
Number of Functions 1
Terminal Position SINGLE
Technology BIPOLAR
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 100ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Tolerance ±1%
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Package / Case E-Line-3
Mounting Type Through Hole
Mount Through Hole
