REF195GS
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Contains Lead GULL WING Non-RoHS Compliant Series Voltage Reference IC 4.9mm ±0.2% 25ppm/C 50muVp-p
PDF
/
Buying Options
Total Price: USD $3.09
Unit Price: USD $3.08845
≥1 USD $3.08845
≥10 USD $2.53365
≥100 USD $2.4548
≥500 USD $2.375
≥1000 USD $2.29615
Inventory: 32898
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Noise - 0.1Hz to 10Hz 50μVp-p
Temp Coef of Voltage-Max 25 ppm/°C
Min Output Voltage 5V
Supply Current-Max (Isup) 0.045mA
Reference Type Series
Max Input Voltage 18V
Max Output Voltage 5V
Quiescent Current 45μA
Nominal Supply Current 45μA
Voltage - Input 5.1V~15V
Operating Supply Current 45μA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Number of Channels 1
Max Output Current 30mA
Output Type Fixed
Output Voltage 5V
Number of Outputs 1
Pin Count 8
Base Part Number REF195
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 45A
Supply Voltage 5.1V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Voltage References
Temperature Coefficient 25ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Tolerance ±0.2%
Series REF19
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
