ADR540BRT-R2
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 ADR540 Cut Tape (CT) OUTPUT VOLTAGE ADJUSTABLE +/-0.5% voltage reference device 50muA 4.096V 85C 0.2%
PDF
/
Buying Options
Total Price: USD $13.25
Unit Price: USD $13.24585
≥1 USD $13.24585
≥10 USD $10.86895
≥100 USD $10.52885
≥500 USD $10.1897
≥1000 USD $9.8496
Inventory: 1133
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 2.92mm
Technical
Cathode Current 50μA
Min Output Voltage 4.096V
Reference Type Shunt
Output Current 15mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Temperature Grade INDUSTRIAL
Output Type Fixed
Output Voltage 4.1V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number ADR540
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.96mm
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Additional Feature OUTPUT VOLTAGE ADJUSTABLE +/-0.5%
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Temperature Coefficient 40 ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Tolerance 0.2%
Packaging Cut Tape (CT)
Physical
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
