ADR444ARZ-REEL7
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 ADR444 Tape & Reel (TR) PRODUCTION (Last Updated: 2weeks ago) voltage reference device 10mA 20V 1.8muVp-p -40C~125C TA
PDF
/
Buying Options
Total Price: USD $4.87
Unit Price: USD $4.8664
≥1 USD $4.8664
≥10 USD $4.39296
≥100 USD $4.188448
≥500 USD $3.636688
≥1000 USD $3.597018
Inventory: 1162
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Noise - 0.1Hz to 10Hz 1.8μVp-p
Min Output Voltage 4.096V
Reference Type Series
Max Input Voltage 20V
Max Output Voltage 4.096V
Quiescent Current 3.75mA
Nominal Supply Current 3.75mA
Voltage - Input 4.6V~18V
Operating Supply Current 3.75mA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Supply Voltage-Min (Vsup) 4.6V
Max Output Current 10mA
Output Type Fixed
Output Voltage 4.096V
Number of Outputs 1
Pin Count 8
Base Part Number ADR444
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Voltage References
Additional Feature OUTPUT VOLTAGE CAN BE ADJUSTED OVER A 0.5 PERCENT RANGE USING TRIM PIN
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 10ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Tolerance ±0.13%
Series XFET?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
