AD1585BRTZ-REEL7
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 AD1585 Tape & Reel (TR) PRODUCTION (Last Updated: 1month ago) voltage reference device 5mA 12V 100muVrms 50ppm/C
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.588829
≥1 USD $2.588829
≥10 USD $2.52473
≥100 USD $2.482869
≥500 USD $10.6343
≥1000 USD $10.27995
≥1000 USD $9.2169
Inventory: 45
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Tolerance ±0.1%
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 50ppm/°C
Terminal Finish Matte Tin (Sn)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 6V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AD1585
Pin Count 3
Number of Outputs 1
Output Voltage 5V
Output Type Fixed
Max Output Current 5mA
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current 70μA
Voltage - Input 5.2V~12V
Nominal Supply Current 70μA
Quiescent Current 70μA
Max Output Voltage 5V
Min Input Voltage 5.2V
Max Input Voltage 12V
Reference Voltage 5V
Reference Type Series
Min Output Voltage 5V
Temp Coef of Voltage-Max 50 ppm/°C
Noise - 0.1Hz to 10Hz 140μVp-p
Noise - 10Hz to 10kHz 100μVrms
Dimensions
Height 1.02mm
Length 3.04mm
Width 1.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
