LTC2991CMS#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TFSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Thermal Management
Description
R-PDSO-G16 ADC Multiplexer Register Bank Tube LTC2991 thermal monitor ±3.5C Local(Max) ±1.5C Remote(Max) 4.039mm 1.5mA 3.3V
PDF
/
Buying Options
Total Price: USD $10.02
Unit Price: USD $10.0232
≥1 USD $10.0232
≥10 USD $9.21184
≥100 USD $8.829726
≥500 USD $7.779754
≥1000 USD $7.397914
≥3000 USD $6.920637
Inventory: 1381
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4.039mm
Height Seated (Max) 1.1mm
Technical
Output Alarm Yes
Sensor Type Internal and External
Supply Current-Max (Isup) 1.5mA
Topology ADC, Multiplexer, Register Bank
Accuracy ±3.5°C Local(Max), ±1.5°C Remote(Max)
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.9V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 5.5V
Output Type I2C
Qualification Status Not Qualified
Function Temp Monitoring System (Sensor)
JESD-30 Code R-PDSO-G16
Base Part Number LTC2991
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.9V~5.5V
Technology CMOS
Subcategory Power Management Circuits
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-TFSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
