TPS3837L30QDBVRQ1
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active High Obsolete DUAL Simple Reset/Power-On Reset Supervisor -40C~125C TA 25muA 437mW 10ms Minimum
PDF
/
Buying Options
Total Price: USD $11.67
Unit Price: USD $11.67455
≥1 USD $11.67455
≥10 USD $9.5798
≥100 USD $9.28055
≥500 USD $8.98035
≥1000 USD $8.6811
Inventory: 7893
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TA
Packaging Cut Tape (CT)
Series Automotive, AEC-Q100
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature RESET THRESHOLD VOLTAGE IS 2.64V
Subcategory Power Management Circuits
Max Power Dissipation 437mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Base Part Number TPS3837L30
Output Push-Pull, Totem Pole
Pin Count 5
Operating Supply Voltage 3V
Power Supplies 3V
Number of Channels 1
Max Supply Voltage 6V
Min Supply Voltage 1.6V
Operating Supply Current 250nA
Nominal Supply Current 25μA
Power Dissipation 437mW
Max Supply Current 25μA
Adjustable Threshold NO
Quiescent Current 220nA
Watchdog Timer No
Reset Active High
Number of Voltages Monitored 1
Reset Timeout 10ms Minimum
Min Reset Threshold Voltage 2.54V
Max Reset Threshold Voltage 2.71V
Threshold Voltage +2.64V
Undervoltage Threshold 2.64V
Overvoltage Threshold 2.71V
Dimensions
Length 2.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
