TPS3837L30DBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tape & Reel (TR) TPS3837L30 RESET THRESHOLD VOLTAGE IS 2.64V supervisor 1.8V 2.9mm 10ms Minimum 437mW
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 1474
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature RESET THRESHOLD VOLTAGE IS 2.64V
Max Power Dissipation 437mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Base Part Number TPS3837L30
Output Push-Pull, Totem Pole
Pin Count 5
Operating Supply Voltage 3V
Number of Channels 1
Max Supply Voltage 6V
Min Supply Voltage 1.6V
Operating Supply Current 250nA
Nominal Supply Current 15μA
Power Dissipation 437mW
Max Supply Current 15μA
Adjustable Threshold NO
Quiescent Current 220nA
Reset Active High
Number of Voltages Monitored 1
Reset Timeout 10ms Minimum
Min Reset Threshold Voltage 2.56V
Max Reset Threshold Voltage 2.69V
Undervoltage Threshold 2.64V
Overvoltage Threshold 2.69V
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
