TPS3823-30QDBVRQ1
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Contains Lead Active Low Obsolete DUAL Simple Reset/Power-On Reset Supervisor -40C~125C TA 25muA 437mW 120ms Minimum
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.147161
≥1 USD $0.147161
≥10 USD $0.138826
≥100 USD $0.130971
≥500 USD $0.123557
≥1000 USD $0.116569
Inventory: 2046
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.75mm
Length 3.05mm
Height 1.3mm
Technical
Overvoltage Threshold 2.69V
Undervoltage Threshold 2.63V
Max Reset Threshold Voltage 2.69V
Min Reset Threshold Voltage 2.55V
Reset Timeout 120ms Minimum
Number of Voltages Monitored 1
Reset Active Low
Watchdog Timer Yes
Quiescent Current 15μA
Adjustable Threshold NO
Max Supply Current 25μA
Power Dissipation 437mW
Nominal Supply Current 25μA
Operating Supply Current 15μA
Min Supply Voltage 1.1V
Max Supply Voltage 5.5V
Number of Channels 1
Pin Count 5
Output Push-Pull, Totem Pole
Base Part Number TPS3823
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 437mW
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 2.63V; MANUAL RESET INPUT; POWER-ON RESET GENERATOR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
