TPS3803G15DCKR
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Cut Tape (CT) TPS3803G15 Simple Reset/Power-On Reset supervisor 1.5V 2mm 5mus Typical Propagation Delay 321mW
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.682
≥100 USD $0.646976
≥500 USD $0.53152
≥1000 USD $0.496848
≥3000 USD $0.439067
Inventory: 1112
Minimum: 1
-
+
Technical Details
Physical
Weight 2.494758mg
Number of Pins 5
Surface Mount YES
Package / Case 5-TSSOP, SC-70-5, SOT-353
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Power Management Circuits
Max Power Dissipation 321mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.5V
Base Part Number TPS3803G15
Output Open Drain or Open Collector
Pin Count 5
Operating Supply Voltage 1.5V
Number of Channels 1
Max Supply Voltage 6V
Min Supply Voltage 1.3V
Operating Supply Current 3μA
Nominal Supply Current 4μA
Power Dissipation 321mW
Max Supply Current 6μA
Adjustable Threshold YES
Quiescent Current 3μA
Accuracy 1.5 %
Reset Active Low
Number of Voltages Monitored 1
Reset Timeout 5μs Typical Propagation Delay
Min Reset Threshold Voltage 1.379V
Max Reset Threshold Voltage 1.421V
Undervoltage Threshold 1.4V
Reset Delay Time 5.5 μs
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
Dimensions
Height 1.1mm
Length 2mm
Width 1.25mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
