TPS3705-30DRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
RoHS Compliant SOIC Nickel/Palladium/Gold (Ni/Pd/Au) EAR99 supervisor 3V 4.9mm 140ms 725mW
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 7670
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 8
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Power Management Circuits
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Pin Count 8
Number of Elements 2
Temperature Grade INDUSTRIAL
Number of Channels 1
Max Supply Voltage 6V
Min Supply Voltage 2V
Analog IC - Other Type POWER SUPPLY MANAGEMENT CIRCUIT
Power Dissipation-Max 725mW
Operating Supply Current 30μA
Nominal Supply Current 50μA
Power Dissipation 725mW
Max Supply Current 50μA
Adjustable Threshold NO
Quiescent Current 30μA
Watchdog Timer Yes
Reset Active Low
Voltage - Threshold 2.63V
Number of Voltages Monitored 1
Reset Timeout 140 ms
Undervoltage Threshold 2.63V
Overvoltage Threshold 2.7V
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
