TPS3306-25DGK
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tube TPS3306 POWER-ON RESET GENERATOR supervisor 3.3V 3mm 70ms Minimum 424mW
PDF
/
Buying Options
Total Price: USD $3.55
Unit Price: USD $3.5464
≥1 USD $3.5464
≥10 USD $3.1856
≥100 USD $2.610194
≥500 USD $2.476294
≥1000 USD $2.221982
≥3000 USD $1.87396
Inventory: 327
Minimum: 1
-
+
Technical Details
Technical
Number of Voltages Monitored 2
Reset Timeout 70ms Minimum
Threshold Voltage +2.932.25V
Undervoltage Threshold 2.93V
Voltage - Threshold 2.25V 2.93V
Reset Active Low
Watchdog Timer Yes
Quiescent Current 15μA
Adjustable Threshold NO
Max Supply Current 40μA
Power Dissipation 424mW
Nominal Supply Current 40μA
Operating Supply Current 15μA
Min Supply Voltage 2.7V
Max Supply Voltage 6V
Number of Channels 2
Power Supplies 3/5V
Max Output Current 5mA
Pin Count 8
Output Open Drain or Open Collector
Base Part Number TPS3306
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 424mW
Subcategory Power Management Circuits
Additional Feature POWER-ON RESET GENERATOR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Multi-Voltage Supervisor
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C TA
Dimensions
Height 1.07mm
Length 3mm
Width 3mm
Thickness 970μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
