TLC7701QPWR
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active High/Active Low Active DUAL Simple Reset/Power-On Reset Supervisor -40C~125C TA 16muA 525mW 1.1ms Minimum
PDF
/
Buying Options
Total Price: USD $15.62
Unit Price: USD $15.623161
≥1 USD $15.623161
≥10 USD $14.738824
≥100 USD $13.90456
≥500 USD $13.117507
≥1000 USD $12.375004
Inventory: 1473
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature POWER-ON RESET GENERATOR
Subcategory Power Management Circuits
Max Power Dissipation 525mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.7V
Terminal Pitch 0.65mm
Base Part Number TLC7701
Output Push-Pull, Totem Pole
Pin Count 8
Number of Channels 1
Max Supply Voltage 6V
Min Supply Voltage 2V
Operating Supply Current 9μA
Power Dissipation 525mW
Max Supply Current 16μA
Adjustable Threshold NO
Quiescent Current 9μA
Watchdog Timer No
Reset Active High/Active Low
Voltage - Threshold 1.1V
Number of Voltages Monitored 1
Reset Timeout 1.1ms Minimum
Min Reset Threshold Voltage 1.04V
Max Reset Threshold Voltage 1.16V
Threshold Voltage +1.1V
Overvoltage Threshold 1.16V
Dimensions
Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
