TL7759CPSRE4
RoHS
/
Package SOP
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
RoHS Compliant SOP RESET THRESHOLD VOLTAGE IS 4.55V; POWER ON RESET GENERATOR Simple Reset/Power-On Reset supervisor 4.3V 6.2mm 5mus 2mA
PDF
/
Inventory: 9874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Length 6.2mm
Height Seated (Max) 2mm
Technical
Overvoltage Threshold 4.67V
Undervoltage Threshold 4.55V
Max Reset Threshold Voltage 4.67V
Min Reset Threshold Voltage 4.43V
Reset Timeout 5 μs
Number of Voltages Monitored 1
Voltage - Threshold 4.55V
Reset Active High
Quiescent Current 1.4mA
Adjustable Threshold NO
Max Supply Current 2mA
Operating Supply Current 1.4mA
Min Supply Voltage 1V
Max Supply Voltage 7V
Number of Channels 1
Temperature Grade COMMERCIAL
Pin Count 8
Supply Voltage 4.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Analog ICs
Additional Feature RESET THRESHOLD VOLTAGE IS 4.55V; POWER ON RESET GENERATOR
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Physical
Number of Pins 8
Package / Case SOP
Mount Surface Mount
