STM805TM6E
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tube STM805 Simple Reset/Power-On Reset supervisor 3.6V 5mm 140ms Minimum 320mW
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9386
≥1 USD $0.9386
≥10 USD $0.77045
≥100 USD $0.7467
≥500 USD $0.722
≥1000 USD $0.69825
Inventory: 1149
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Power Management Circuits
Max Power Dissipation 320mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.6V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STM805
Output Open Drain or Open Collector
Pin Count 8
Power Supplies 3.3/5V
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1V
Operating Supply Current 60μA
Nominal Supply Current 60μA
Power Dissipation 320mW
Max Supply Current 60μA
Adjustable Threshold NO
Watchdog Timer Yes
Reset Active High
Voltage - Threshold 3.075V
Number of Voltages Monitored 1
Reset Timeout 140ms Minimum
Min Reset Threshold Voltage 3V
Max Reset Threshold Voltage 3.15V
Undervoltage Threshold 3V
Overvoltage Threshold 3.15V
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
