STM704M6E
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tape & Reel (TR) STM704 Simple Reset/Power-On Reset supervisor 5V 4.9mm 140ms Minimum 320mW
PDF
/
Inventory: 1331
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Overvoltage Threshold 4.5V
Undervoltage Threshold 4.25V
Max Reset Threshold Voltage 4.5V
Min Reset Threshold Voltage 4.25V
Reset Timeout 140ms Minimum
Number of Voltages Monitored 1
Voltage - Threshold 4.4V
Reset Active Low
Watchdog Timer No
Adjustable Threshold NO
Max Supply Current 60μA
Power Dissipation 320mW
Nominal Supply Current 60μA
Operating Supply Current 60μA
Min Supply Voltage 1V
Max Supply Voltage 5.5V
Number of Channels 1
Power Supplies 5V
Pin Count 8
Output Push-Pull, Totem Pole
Base Part Number STM704
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 320mW
Subcategory Power Management Circuits
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
