CAT1024ZI45
RoHS
/
Package MSOP
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
DUAL GULL WING POWER SUPPLY SUPPORT CIRCUIT CMOS supervisor 85C 3mA 1W 3mm
PDF
/
Inventory: 7680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 8
Temperature Grade INDUSTRIAL
Number of Channels 1
Max Supply Voltage 3V
Min Supply Voltage 2.7V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Power Dissipation-Max 1W
Operating Supply Current 3mA
Max Supply Current 3mA
Adjustable Threshold NO
Number of Voltages Monitored 5
Min Reset Threshold Voltage 4.5V
Max Reset Threshold Voltage 4.75V
Undervoltage Threshold 4.75V
Overvoltage Threshold 4.75V
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Physical
Number of Pins 8
Package / Case MSOP
Mount Surface Mount
