SG3544J
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
DUAL POWER SUPPLY SUPPORT CIRCUIT BIPOLAR Through Hole supervisor 70C 10mA 5.08mm 10V
PDF
/
Inventory: 5496
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 weeks ago)
Physical
Mount Through Hole
Package / Case CDIP
Technical
JESD-609 Code e0
Number of Terminations 18
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 70°C
Min Operating Temperature 0°C
HTS Code 8542.39.00.01
Subcategory Power Management Circuits
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 1
Supply Voltage 10V
Terminal Pitch 2.54mm
Pin Count 18
Temperature Grade COMMERCIAL
Number of Channels 1
Max Supply Voltage 40V
Min Supply Voltage 4.7V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Max Supply Current 10mA
Adjustable Threshold NO
Dimensions
Height Seated (Max) 5.08mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
