TC1272ARVNBTR
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tape & Reel (TR) TC1272A Simple Reset/Power-On Reset supervisor 3V 2.92mm 140ms Minimum 320mW
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.814587
≥1 USD $0.814587
≥10 USD $0.768476
≥100 USD $0.724977
≥500 USD $0.683936
≥1000 USD $0.645221
Inventory: 1506
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2013
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Matte Tin (Sn)
Subcategory Power Management Circuits
Max Power Dissipation 320mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.96mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC1272A
Output Push-Pull, Totem Pole
Pin Count 3
Power Supplies 3V
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1V
Operating Supply Current 9μA
Power Dissipation 320mW
Adjustable Threshold NO
Quiescent Current 12μA
Watchdog Timer No
Reset Active Low
Voltage - Threshold 2.63V
Number of Voltages Monitored 1
Reset Timeout 140ms Minimum
Supply Current-Max (Isup) 0.025mA
Min Reset Threshold Voltage 2.59V
Max Reset Threshold Voltage 2.66V
Threshold Voltage +2.63V
Undervoltage Threshold 2.59V
Overvoltage Threshold 2.66V
Dimensions
Length 2.92mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
