TC1270LERCTR
RoHS
RoHS compliant
RoHS compliantPackage TO-253-4, TO-253AA
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tape & Reel (TR) TC1270L Simple Reset/Power-On Reset supervisor 5V 2.86mm 140ms Minimum 10muA
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.45695
≥1 USD $0.45695
≥10 USD $0.37525
≥100 USD $0.3629
≥500 USD $0.3515
≥1000 USD $0.3401
Inventory: 3207
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 2.86mm
Technical
Overvoltage Threshold 4.72V
Undervoltage Threshold 4.54V
Max Reset Threshold Voltage 4.72V
Min Reset Threshold Voltage 4.54V
Reset Timeout 140ms Minimum
Number of Voltages Monitored 1
Voltage - Threshold 4.63V
Reset Active Low
Watchdog Timer No
Adjustable Threshold NO
Operating Supply Current 10μA
Min Supply Voltage 1.2V
Max Supply Voltage 5.5V
Number of Channels 1
Pin Count 4
Output Push-Pull, Totem Pole
Base Part Number TC1270L
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 4
Package / Case TO-253-4, TO-253AA
Mounting Type Surface Mount
Mount Surface Mount
