MIC706TMY
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tube MIC706 WATCHDOG TIMER MANUAL RESET INPUT supervisor 5V 4.9mm 140ms Minimum 400mW
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.1
≥1 USD $1.1
≥10 USD $0.9064
≥100 USD $0.836
Inventory: 927
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2006
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature WATCHDOG TIMER, MANUAL RESET INPUT
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MIC706
Number of Channels 2
Max Supply Voltage 5.5V
Min Supply Voltage 1.4V
Nominal Supply Current 30μA
Power Dissipation 400mW
Adjustable Threshold NO
Watchdog Timer Yes
Reset Active Low
Voltage - Threshold 3.08V
Number of Voltages Monitored 1
Reset Timeout 140ms Minimum
Min Reset Threshold Voltage 3V
Max Reset Threshold Voltage 3.15V
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
