MAX6868UK18D6L+T
RoHS
/
Package SOT-23-5
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active High DUAL GULL WING supervisor 85C 7muA 571mW 600ms
PDF
/
Inventory: 7637
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 2.9mm
Technical
Overvoltage Threshold 1.845V
Undervoltage Threshold 1.755V
Max Reset Threshold Voltage 1.845V
Min Reset Threshold Voltage 1.755V
Reset Timeout 600 ms
Number of Voltages Monitored 1
Voltage - Threshold 1.8V
Reset Active High
Watchdog Timer Yes
Adjustable Threshold NO
Operating Supply Current 7μA
Power Dissipation-Max 571mW
Min Supply Voltage 1.1V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade INDUSTRIAL
Pin Count 5
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish MATTE TIN
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 5
Package / Case SOT-23-5
Mount Surface Mount
