MAX6864UK20D4S+
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
DUAL GULL WING POWER SUPPLY MANAGEMENT CIRCUIT BICMOS supervisor 85C 571mW 2.9mm 2.5V
PDF
/
Buying Options
Total Price: USD $8.67
Unit Price: USD $8.667571
≥1 USD $8.667571
≥10 USD $8.176951
≥100 USD $7.714105
≥500 USD $7.277465
≥1000 USD $6.865527
Inventory: 1154
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 2.9mm
Technical
Max Reset Threshold Voltage 2.05V
Min Reset Threshold Voltage 1.95V
Watchdog Timer Yes
Adjustable Threshold NO
Power Dissipation-Max 571mW
Analog IC - Other Type POWER SUPPLY MANAGEMENT CIRCUIT
Min Supply Voltage 1.2V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade INDUSTRIAL
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 2V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Physical
Number of Pins 5
Package / Case SOT-23
Mount Surface Mount
