MAX6858UK39D4+T
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active Low DUAL GULL WING supervisor 85C 7muA 571mW 1.2s
PDF
/
Inventory: 3084
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish MATTE TIN
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Power Management Circuits
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 5
Temperature Grade INDUSTRIAL
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1.1V
Power Dissipation-Max 571mW
Operating Supply Current 7μA
Adjustable Threshold NO
Reset Active Low
Voltage - Threshold 3.9V
Number of Voltages Monitored 1
Reset Timeout 1.2 s
Min Reset Threshold Voltage 3.802V
Max Reset Threshold Voltage 3.998V
Undervoltage Threshold 3.802V
Overvoltage Threshold 3.998V
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Number of Pins 5
Package / Case SOT-23
Mount Surface Mount
