MAX6855UK46D3+T
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
ROHS3Compliant Tape & Reel (TR) MAX6855 Simple Reset/Power-On Reset supervisor 2.5V 2.9mm 150ms Minimum 571mW
PDF
/
Inventory: 1261
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Terminal Finish TIN
Subcategory Power Management Circuits
Max Power Dissipation 571mW
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Base Part Number MAX6855
Output Push-Pull, Totem Pole
Pin Count 5
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1.1V
Operating Supply Current 7μA
Adjustable Threshold NO
Watchdog Timer No
Reset Active High
Voltage - Threshold 4.625V
Number of Voltages Monitored 1
Reset Timeout 150ms Minimum
Min Reset Threshold Voltage 4.509V
Max Reset Threshold Voltage 4.741V
Undervoltage Threshold 4.509V
Overvoltage Threshold 4.741V
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
