MAX6836HXSD2+T
RoHS
/
Package SC
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active High DUAL GULL WING supervisor 85C 0.025mA 245mW 20ms
PDF
/
Inventory: 8984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Min Operating Temperature -40°C
Subcategory Power Management Circuits
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.2V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 4
JESD-30 Code R-PDSO-G4
Temperature Grade INDUSTRIAL
Number of Channels 1
Max Supply Voltage 3.6V
Min Supply Voltage 750mV
Power Dissipation-Max 245mW
Operating Supply Current 16μA
Adjustable Threshold NO
Watchdog Timer No
Reset Active High
Voltage - Threshold 1.313V
Number of Voltages Monitored 1
Reset Timeout 20 ms
Supply Current-Max (Isup) 0.025mA
Min Reset Threshold Voltage 1.275V
Max Reset Threshold Voltage 1.35V
Threshold Voltage +1.313V
Undervoltage Threshold 1.275V
Overvoltage Threshold 1.35V
Max Operating Temperature 85°C
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
Packaging Tape & Reel (TR)
Dimensions
Length 2mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Package / Case SC
Mount Surface Mount
