MAX6464XR55+T
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active Low DUAL GULL WING supervisor 125C 3.5muA 228.6mW 150ms
PDF
/
Inventory: 5099
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Number of Pins 3
Technical
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 3
ECCN Code EAR99
Type Simple Reset/Power-On Reset
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 3.6V
Terminal Pitch 0.65mm
Pin Count 3
Temperature Grade AUTOMOTIVE
Number of Channels 1
Max Supply Voltage 6V
Min Supply Voltage 1.2V
Power Dissipation-Max 228.6mW
Operating Supply Current 3.5μA
Max Supply Current 3.5μA
Adjustable Threshold NO
Accuracy 2.5 %
Watchdog Timer No
Reset Active Low
Voltage - Threshold 5.5V
Reset Timeout 150 ms
Min Reset Threshold Voltage 5.418V
Max Reset Threshold Voltage 5.583V
Undervoltage Threshold 5.418V
Overvoltage Threshold 5.583V
Number of Monitored Inputs 1
Reset Delay Time 260 ms
Dimensions
Length 2mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
