MAX6425UK40+T
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
RoHS Compliant Tape & Reel (TR) RESET THRESHOLD VOLTAGE IS 4.0V Simple Reset/Power-On Reset supervisor 5V 2.9mm 571mW 2.5muA
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.317442
≥1 USD $1.317442
≥10 USD $1.242867
≥100 USD $1.172519
≥500 USD $1.106148
≥1000 USD $1.043532
Inventory: 1147
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 2.9mm
Technical
Overvoltage Threshold 4.1V
Undervoltage Threshold 3.9V
Threshold Voltage +4.0V
Max Reset Threshold Voltage 4.1V
Min Reset Threshold Voltage 3.9V
Supply Current-Max (Isup) 0.0042mA
Number of Voltages Monitored 1
Voltage - Threshold 4V
Reset Active Low
Watchdog Timer No
Adjustable Threshold NO
Operating Supply Current 2.5μA
Power Dissipation-Max 571mW
Min Supply Voltage 1V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade AUTOMOTIVE
Pin Count 5
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 4.0V
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Physical
Number of Pins 5
Package / Case SOT-23
Mount Surface Mount
