MAX6386LT33D3+T
RoHS
/
Package WFDFN
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Active Low DUAL BICMOS Surface Mount supervisor 125C 7muA 167.7mW 140ms
PDF
/
Inventory: 3533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 6
Temperature Grade AUTOMOTIVE
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1V
Power Dissipation-Max 167.7mW
Operating Supply Current 7μA
Adjustable Threshold NO
Watchdog Timer No
Reset Active Low
Voltage - Threshold 3.3V
Number of Voltages Monitored 1
Reset Timeout 140 ms
Min Reset Threshold Voltage 3.22V
Max Reset Threshold Voltage 3.38V
Undervoltage Threshold 3.22V
Overvoltage Threshold 3.38V
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 3.3V; MANUAL RESET INPUT
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Dimensions
Height Seated (Max) 0.8mm
Compliance
RoHS Status RoHS Compliant
Physical
Number of Pins 6
Package / Case WFDFN
Mount Surface Mount
