MAX6316LUK29CX+
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
DUAL GULL WING POWER SUPPLY MANAGEMENT CIRCUIT Surface Mount supervisor 125C 0.02mA 571mW 2.9mm
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
Inventory: 4508
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOT-23
Number of Pins 5
Technical
JESD-609 Code e3
Moisture Sensitivity Level (MSL) 1
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Additional Feature RESET THRESHOLD VOLTAGE IS 2.93V
Subcategory Power Management Circuits
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.6V
Time@Peak Reflow Temperature-Max (s) 30
Temperature Grade AUTOMOTIVE
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1V
Analog IC - Other Type POWER SUPPLY MANAGEMENT CIRCUIT
Power Dissipation-Max 571mW
Adjustable Threshold NO
Watchdog Timer Yes
Supply Current-Max (Isup) 0.02mA
Min Reset Threshold Voltage 2.886V
Max Reset Threshold Voltage 2.974V
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
