MAX6315US25D4
RoHS
/
Package SOT-143
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
DUAL GULL WING POWER SUPPLY SUPPORT CIRCUIT CMOS supervisor 125C 0.015mA 320mW 2.92mm
PDF
/
Inventory: 3874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.3mm
Length 2.92mm
Height Seated (Max) 1.22mm
Technical
Threshold Voltage 2.50
Max Reset Threshold Voltage 2.54V
Min Reset Threshold Voltage 2.46V
Supply Current-Max (Isup) 0.015mA
Adjustable Threshold YES
Power Dissipation-Max 320mW
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade AUTOMOTIVE
Pin Count 4
Terminal Pitch 1.92mm
Supply Voltage 3.6V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Physical
Number of Pins 4
Package / Case SOT-143
Mount Surface Mount
