MAX6314US30D2-T
RoHS
/
Package TO-253-4
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
Lead Free Active Low DUAL GULL WING supervisor 85C 5muA 320mW 20ms
PDF
/
Inventory: 6947
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 2.92mm
Technical
Overvoltage Threshold 3.05V
Undervoltage Threshold 2.95V
Threshold Voltage +3V
Max Reset Threshold Voltage 3.05V
Min Reset Threshold Voltage 2.95V
Reset Timeout 20 ms
Number of Voltages Monitored 1
Voltage - Threshold 3V
Reset Active Low
Watchdog Timer No
Adjustable Threshold NO
Operating Supply Current 5μA
Power Dissipation-Max 320mW
Min Supply Voltage 1V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade INDUSTRIAL
Pin Count 4
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 3V; MANUAL RESET INPUT
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Simple Reset/Power-On Reset
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Physical
Number of Pins 4
Package / Case TO-253-4
Mount Surface Mount
