MAX6314US28D4
RoHS
/
Package SOT-143
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description
DUAL GULL WING POWER SUPPLY SUPPORT CIRCUIT CMOS supervisor 85C 0.012mA 320mW 2.92mm
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
Inventory: 1168
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.3mm
Length 2.92mm
Height Seated (Max) 1.22mm
Technical
Threshold Voltage +2.8V
Max Reset Threshold Voltage 2.85V
Min Reset Threshold Voltage 2.75V
Supply Current-Max (Isup) 0.012mA
Adjustable Threshold NO
Power Dissipation-Max 320mW
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade INDUSTRIAL
Pin Count 4
Terminal Pitch 1.92mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 2.8V; MANUAL RESET INPUT
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Physical
Number of Pins 4
Package / Case SOT-143
Mount Surface Mount
