MAX6314US25D2

Maxim Integrated
RoHS
/
Package SOT-143
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description DUAL GULL WING POWER SUPPLY SUPPORT CIRCUIT CMOS supervisor 85C 0.012mA 320mW 2.92mm
PDF
/
Inventory: 6368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Max Supply Voltage 5.5V
Min Supply Voltage 1V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Power Dissipation-Max 320mW
Adjustable Threshold NO
Supply Current-Max (Isup) 0.012mA
Min Reset Threshold Voltage 2.46V
Max Reset Threshold Voltage 2.55V
Threshold Voltage +2.5V
Number of Channels 1
Temperature Grade INDUSTRIAL
Pin Count 4
Terminal Pitch 1.92mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 2.5V; MANUAL RESET INPUT
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Packaging Cut Tape

Dimensions

Height Seated (Max) 1.22mm
Length 2.92mm
Width 1.3mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant

Physical

Number of Pins 4
Package / Case SOT-143
Mount Surface Mount
