LTC2935CDC-1#TRMPBF image
Favorite
LTC2935CDC-1#TRMPBF image
Favorite
RoHS
RoHS RoHS compliant
Package 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Supervisors
Description ROHS3Compliant Tape & Reel (TR) LTC2935 SELECTABLE THRESHOLD VOLTAGE; MANUAL RESET INPUT supervisor 3.6V 2mm 140ms Minimum 0C~70C TA
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.5288
≥1 USD $3.5288
≥10 USD $3.17328
≥100 USD $2.999744
≥500 USD $2.599696
≥1000 USD $2.466429
Inventory: 232
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mounting Type Surface Mount
Package / Case 8-WFDFN Exposed Pad
Surface Mount YES

Technical

Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Multi-Voltage Supervisor
Terminal Finish Matte Tin (Sn)
Additional Feature SELECTABLE THRESHOLD VOLTAGE; MANUAL RESET INPUT
Subcategory Power Management Circuits
Technology CMOS
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.6V
Terminal Pitch 0.45mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LTC2935
Output Open Drain or Open Collector
Pin Count 8
JESD-30 Code S-PDSO-N8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.6V
Supply Voltage-Min (Vsup) 1V
Number of Channels 1
Adjustable Threshold NO
Reset Active Low
Voltage - Threshold 8 Selectable Threshold Combinations
Number of Voltages Monitored 1
Reset Timeout 140ms Minimum

Dimensions

Height Seated (Max) 0.8mm
Length 2mm
Width 2mm

Compliance

RoHS Status ROHS3 Compliant
