LM25115MT
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
LM25115 EAR99 Secondary-Side Controller Tube power supply monitor 5mm 4.5V~30V 1MHz 4mA
PDF
/
Buying Options
Total Price: USD $1.74
Unit Price: USD $1.73565
≥1 USD $1.73565
≥10 USD $1.42405
≥100 USD $1.3794
≥500 USD $1.33475
≥1000 USD $1.29105
Inventory: 1606
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.4mm
Length 5mm
Technical
Switching Frequency 1MHz
Switcher Configuration PUSH-PULL
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT/VOLTAGE-MODE
Output Power 300W
Output Current 20A
Voltage - Input 0V~42V
Operating Supply Current 4mA
Analog IC - Other Type SWITCHING CONTROLLER
Power Supplies 4.5/7V
Input Voltage-Nom 12V
Output Voltage 13.5V
Number of Outputs 1
Pin Count 16
Base Part Number LM25115
Frequency 250kHz
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~30V
Subcategory Power Management Circuits
Applications Secondary-Side Controller
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
