L6599DTR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
L6599 EAR99 Resonant Converter Controller Tape & Reel (TR) power supply controller 9.9mm 8.85V~16V 500kHz 5mA
PDF
/
Buying Options
Total Price: USD $2.22
Unit Price: USD $2.2176
≥1 USD $2.2176
≥10 USD $1.99232
≥100 USD $1.87968
≥500 USD $1.6016
≥1000 USD $1.50385
≥3000 USD $1.315864
Inventory: 1540
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 200.686274mg
Technical
Operating Temperature 0°C~105°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Resonant Converter Controller
Subcategory Power Management Circuits
Voltage - Supply 8.85V~16V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 15V
Frequency 500kHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L6599
Pin Count 16
Input Voltage-Nom 15V
Number of Channels 1
Analog IC - Other Type SWITCHING CONTROLLER
Operating Supply Current 3.5mA
Output Current 800mA
Max Supply Current 5mA
Input Voltage (Min) 8.85V
Control Mode VOLTAGE-MODE
Control Technique RESONANT CONTROL
Switcher Configuration PUSH-PULL
Max Duty Cycle 52 %
Switching Frequency 500kHz
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
