L6599D
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
L6599 EAR99 Resonant Converter Controller Tube power supply controller 10mm 8.85V~16V 500kHz 5mA
PDF
/
Buying Options
Total Price: USD $2.22
Unit Price: USD $2.2176
≥1 USD $2.2176
≥10 USD $1.99232
≥100 USD $1.879856
≥500 USD $1.6016
≥1000 USD $1.50385
≥3000 USD $1.315864
Inventory: 1008
Minimum: 1
-
+
Technical Details
Technical
Applications Resonant Converter Controller
Subcategory Power Management Circuits
Voltage - Supply 8.85V~16V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 15V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L6599
Pin Count 16
Number of Outputs 1
Output Voltage 600V
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Operating Supply Current 3.5mA
Output Current 800mA
Max Supply Current 5mA
Input Voltage (Min) 8.85V
Control Mode VOLTAGE-MODE
Control Technique RESONANT CONTROL
Switcher Configuration PUSH-PULL
Max Duty Cycle 52 %
Switching Frequency 500kHz
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~105°C
Dimensions
Height 1.6mm
Length 10mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
Alternative Model
