LTC4151CS-2#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
DUAL CMOS GULL WING Surface Mount Power Supply Monitor 0C~70C 1.2mA 7V~80V 9.906mm
PDF
/
Buying Options
Total Price: USD $6.64
Unit Price: USD $6.644
≥1 USD $6.644
≥10 USD $6.00072
≥100 USD $5.721232
≥500 USD $4.967688
≥1000 USD $4.744397
≥3000 USD $4.325798
Inventory: 63
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.899mm
Length 9.906mm
Height Seated (Max) 1.752mm
Technical
Supply Current-Max (Isup) 1.7mA
Current - Supply 1.2mA
Adjustable Threshold NO
Voltage - Input 7V~80V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 7V
Power Supplies 7/80V
Supply Voltage-Max (Vsup) 80V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number LTC4151
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 7V~80V
Technology CMOS
Subcategory Power Management Circuits
HTS Code 8542.39.00.01
Applications Power Supply Monitor
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
