LTC3766IGN
RoHS
/
Package 28-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
DUAL CMOS GULL WING PULSE WIDTH MODULATION Synchronous Forward Controller -40C~125C 5mA 316kHz 5V~10V
PDF
/
Buying Options
Total Price: USD $9.72
Unit Price: USD $9.720407
≥1 USD $9.720407
≥10 USD $9.170197
≥100 USD $8.651134
≥500 USD $8.161454
≥1000 USD $7.699483
Inventory: 1180
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.899mm
Length 9.893mm
Height Seated (Max) 1.75mm
Technical
Switching Frequency-Max 316kHz
Switcher Configuration PUSH-PULL
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Current - Supply 5mA
Voltage - Input 5V~32V
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 15V
Output Voltage 7V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.635mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V~10V
Technology CMOS
Subcategory Switching Regulator or Controllers
HTS Code 8542.39.00.01
Additional Feature 8.5V OUTPUT VOLTAGE AVAILABLE, ALSO HAS CONTROL MODE OF IPK
Applications Synchronous Forward Controller
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series Direct Flux Limit?, PolyPhase?
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 28-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
