LTC1041CS8#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
LTC1041 8542.39.00.01 Bang-Bang Controller Tape & Reel (TR) power supply controller 4.9025mm 2.8V~16V 1.2mA -40C~85C
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.203906
≥1 USD $4.203906
≥200 USD $1.626683
≥500 USD $1.570228
≥1000 USD $1.541345
Inventory: 1362
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.899mm
Length 4.9025mm
Height Seated (Max) 1.752mm
Technical
Current - Supply 1.2mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 2.8V
Supply Voltage-Max (Vsup) 16V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number LTC1041
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.8V~16V
Technology CMOS
HTS Code 8542.39.00.01
Applications Bang-Bang Controller
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
