TPS2376DG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Over Ethernet (PoE) Controllers
Description
DUAL GULL WING Lead Free Nickel/Palladium/Gold (Ni/Pd/Au) Power Over Ethernet Controller (PD) -40C~85C 12.95W 0V~57V 1.58mm
PDF
/
Buying Options
Total Price: USD $7.73
Unit Price: USD $7.726411
≥1 USD $7.726411
≥10 USD $7.289065
≥100 USD $6.876474
≥500 USD $6.487239
≥1000 USD $6.120041
Inventory: 1218
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Auxiliary Sense No
Standards 802.3af (PoE)
Min Current Limit 405mA
Internal Switch(s) Yes
Nominal Input Voltage 57V
Supply Current-Max (Isup) 0.45mA
Current - Supply 240μA
Power - Max 12.95W
Adjustable Threshold NO
Output Current 350mA
Power Dissipation 13W
Number of Channels 1
Pin Count 8
Base Part Number TPS2376
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 0V~57V
Subcategory Power Management Circuits
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Controller (PD)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 72.603129mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
