PM8801TR
RoHS
/
Package 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Over Ethernet (PoE) Controllers
Description
DUAL GULL WING RoHS Compliant 802.3at (PoE+) 802.3af (PoE) power over ethernet controller -40C~85C 25.3W 48V 7.8mm
PDF
/
Buying Options
Total Price: USD $1.44
Unit Price: USD $1.44305
≥1 USD $1.44305
≥10 USD $1.18465
≥100 USD $1.1476
≥500 USD $1.11055
≥1000 USD $1.0735
Inventory: 1137
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 4.4mm
Length 7.8mm
Technical
Auxiliary Sense Yes
Standards 802.3at (PoE+), 802.3af (PoE)
Internal Switch(s) No
Current - Supply 640mA
Power - Max 25.3W
Number of Channels 2
Base Part Number PM8801
Terminal Pitch 0.65mm
Supply Voltage 48V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Type Controller (PD), DC/DC
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
