PM8800A
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Over Ethernet (PoE) Controllers
Description
PM8800 Active Tube e4 power over ethernet controller 3mA 1mm 48V 12.95W
PDF
/
Buying Options
Total Price: USD $2.63
Unit Price: USD $2.6312
≥1 USD $2.6312
≥10 USD $2.36104
≥100 USD $1.93417
≥500 USD $1.835011
≥1000 USD $1.646559
≥3000 USD $1.388658
Inventory: 1942
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Type Controller (PD), DC/DC
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Power Dissipation 12.95W
Voltage - Supply 48V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number PM8800
Pin Count 16
Operating Supply Voltage 10V
Number of Channels 1
Operating Supply Current 3mA
Internal Switch(s) Both
Standards 802.3af (PoE)
Auxiliary Sense No
Dimensions
Height 1mm
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
