SI3401-E1-GM

Silicon Labs
RoHS
/
Package 20-VQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Over Ethernet (PoE) Controllers
Description SI3401 Obsolete Tube Controller (PD) DC/DC power over ethernet controller 2mA 5mm 2.8V~57V 15W
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 805
Minimum: 1
-
+

Technical Details

Physical

Package / Case 20-VQFN Exposed Pad
Surface Mount YES
Number of Pins 20
Weight 61.603514mg

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Published 1999
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Termination SMD/SMT
Type Controller (PD), DC/DC
Max Power Dissipation 15W
Voltage - Supply 2.8V~57V
Terminal Position QUAD
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.8mm
Frequency 350kHz
Base Part Number SI3401
Pin Count 20
Number of Channels 1
Operating Supply Current 2mA
Nominal Supply Current 2mA
Power Dissipation 1.2W
Output Current 2A
Min Input Voltage 2.8V
Max Input Voltage 57V
Internal Switch(s) Yes
Standards 802.3af (PoE)
Auxiliary Sense No

Dimensions

Height Seated (Max) 0.9mm
Length 5mm
Width 5mm

Compliance

REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
