TPS2383BPMG4
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / PMIC - Power Over Ethernet (PoE) Controllers
Description
Obsolete Tray S-PQFP-G64 Controller (PSE) power over ethernet controller 5mA 10mm 44V~57V 15.4W
PDF
/
Buying Options
Total Price: USD $14.42
Unit Price: USD $14.4232
≥1 USD $14.4232
Inventory: 358
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.6mm
Technical
Standards 802.3af (PoE)
Internal Switch(s) No
Current - Supply 5mA
Power - Max 15.4W
Adjustable Threshold NO
Number of Channels 8
Supply Voltage-Min (Vsup) 44V
Supply Voltage-Max (Vsup) 57V
JESD-30 Code S-PQFP-G64
Pin Count 64
Terminal Pitch 0.5mm
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 44V~57V
Terminal Finish NICKEL PALLADIUM GOLD
Type Controller (PSE)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 64-LQFP
