MAX5941BCSE+
RoHS
RoHS compliant
RoHS compliantPackage /
Category Integrated Circuits (ICs) / PMIC - Power Over Ethernet (PoE) Controllers
Description
Obsolete Tube BICMOS 8542.31.00.01 power over ethernet controller 0.3A 9.9mm 48V 314kHz
PDF
/
Buying Options
Total Price: USD $5.11
Unit Price: USD $5.1072
≥1 USD $5.1072
≥10 USD $4.19045
≥100 USD $4.05935
≥500 USD $3.92825
≥1000 USD $3.79715
Inventory: 7002
Minimum: 1
-
+
Technical Details
Technical
ECCN Code EAR99
Terminal Finish TIN
Max Operating Temperature 70°C
Min Operating Temperature 0°C
HTS Code 8542.31.00.01
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 48V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 67V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 18V
Number of Channels 1
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold YES
Control Mode CURRENT-MODE
Output Current-Max 0.3A
Switching Frequency-Max 314kHz
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tube
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
