TPS65167RHAR
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
Not Qualified ROHS3Compliant Contains Lead PULSE WIDTH MODULATION LCD TV/Monitor 4.9A -40C~85C 750kHz 14V
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.53305
≥1 USD $3.53305
≥10 USD $2.89845
≥100 USD $2.8082
≥500 USD $2.717
≥1000 USD $2.62675
Inventory: 19041
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 40
Weight 103.986051mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 40
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications LCD TV/Monitor
HTS Code 8542.39.00.01
Subcategory Power Management Circuits
Voltage - Supply 6V~14V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 0.5mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TPS65167
Pin Count 40
Qualification Status Not Qualified
Input Voltage-Nom 12V
Power Supplies 12V
Analog IC - Other Type SWITCHING REGULATOR
Min Input Voltage 6V
Control Mode VOLTAGE-MODE
Output Current-Max 4.9A
Max Input Voltage 14V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BOOST
Switching Frequency 750kHz
Dimensions
Height Seated (Max) 1mm
Length 6mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
